DSR-10 Digital Shaking Rotator
DSR-10 Digital Shaking Rotator
Model: Digital Shaking Rotator
Brand: KANGJIAN
Numbering: DSR-10
Product Overview
◎ With multiple types of fixing clips, it can carry out the mixing and shaking for vessels of different shape and size.
◎ Two operation methods for choice: circling and reciprocating.
◎ Compact structure. With BLDCM (Brushless DC Motor), the equipment can run smoothly with little noise for long time.
◎ LCD with backlight can display the current speed, time and operation mode, convenient for reading and setting.
◎ Precise digital time and speed setting can easily carry out the continuous operation mode.
◎ Safe operating protection function adopted.
◎ Maximum load reaches 7.5KG.
◎ Wide voltage design avoids the impact of unstable voltage on the equipment.
Specifications
| Operation method: | Circling, Reciprocating |
| Shaker diameter: | 10mm |
| Maximum loading weight (incl. Fixing clips): | 7.5kg |
| Equipment input power: | 40W |
| Motor output power: | 10W |
| Motor type: | BLDC |
| Speed range: | 100-500rpm / 40-350rpm |
| Speed display: | LCD |
| Timer display: | LCD |
| Time setting range: | 0-99h59min |
| Operation mode: | Timing/Continuous |
| Shaking table lock: | Yes |
| Dimensions (W×H×D): | 420×360×100mm |
| Weight: | 13kg |
| Permissible ambient temperature: | 5-50°C |
| Permissible relative moisture: | 80% |
| Protection class according to DIN EN 60529: | IP21 |
| Analog output: | Yes |
| Voltage: | AC 100-240V |
| Frequency: | 50/60Hz |
